TL304
TAVOL
8701921000
Specification
| 30HP tractor 8+2 gears | ||||
| Model | TL304 | |||
| Type | 4×4Wheel | |||
| Calibration traction | kN | 6.5 | ||
| Power output shaft maximum power | kw | 18.8 | ||
| Shape | Long | mm | 3220 | |
| Width | mm | 1455 | ||
| High (to muffler) | mm | 2225 | ||
| Wheelbase | 1730 | |||
| Size track | Front wheel | mm | 1225-1425 | |
| Rear wheel | mm | 960-1300 | ||
| Ground clearance | Minimum ground clearance | mm | 290 | |
| Agricultural gap | mm | 400(Lower axle face of front axle axle housing) | ||
| Turning circle radius | Unilateral braking | m | ≤2.3 | |
| Not unilateral braking | m | ≤3 | ||
| Structural quality | kg | 1400 | ||
| Minimum use quality | kg | 1400 | ||
| Mass distribution | Front wheel | kg | 1300 | |
| Rear wheel | kg | 1700 | ||
| Tire specifications | Front wheel | 5.0-12 | ||
| Rear wheel | 9.5-16 | |||
| Working equipment | Suspension mechanism | 3-piont suspension type 1 or 2 | ||
| Maximum lifting force at 610mm(KN) | ≥17 | |||
| PTO shaft | Type | Rear, non-independent | ||
| Rotating speed | r/mim | 540/760 | ||
Features
A 30hp tractor can meet the basic farming needs of small and medium-sized farms (such as rotary tillage, sowing, and transportation) without wasting fuel due to excessive power, and is more economical.
Moderate size, suitable for operation in greenhouses, orchards, hills and other narrow or complex terrains, small turning radius, easy to operate
It can be equipped with a variety of agricultural tools, such as rotary tillers, seed drills, trailers, etc., to achieve integrated operations of tilling, planting and transportation.
Specification
| 30HP tractor 8+2 gears | ||||
| Model | TL304 | |||
| Type | 4×4Wheel | |||
| Calibration traction | kN | 6.5 | ||
| Power output shaft maximum power | kw | 18.8 | ||
| Shape | Long | mm | 3220 | |
| Width | mm | 1455 | ||
| High (to muffler) | mm | 2225 | ||
| Wheelbase | 1730 | |||
| Size track | Front wheel | mm | 1225-1425 | |
| Rear wheel | mm | 960-1300 | ||
| Ground clearance | Minimum ground clearance | mm | 290 | |
| Agricultural gap | mm | 400(Lower axle face of front axle axle housing) | ||
| Turning circle radius | Unilateral braking | m | ≤2.3 | |
| Not unilateral braking | m | ≤3 | ||
| Structural quality | kg | 1400 | ||
| Minimum use quality | kg | 1400 | ||
| Mass distribution | Front wheel | kg | 1300 | |
| Rear wheel | kg | 1700 | ||
| Tire specifications | Front wheel | 5.0-12 | ||
| Rear wheel | 9.5-16 | |||
| Working equipment | Suspension mechanism | 3-piont suspension type 1 or 2 | ||
| Maximum lifting force at 610mm(KN) | ≥17 | |||
| PTO shaft | Type | Rear, non-independent | ||
| Rotating speed | r/mim | 540/760 | ||
Features
A 30hp tractor can meet the basic farming needs of small and medium-sized farms (such as rotary tillage, sowing, and transportation) without wasting fuel due to excessive power, and is more economical.
Moderate size, suitable for operation in greenhouses, orchards, hills and other narrow or complex terrains, small turning radius, easy to operate
It can be equipped with a variety of agricultural tools, such as rotary tillers, seed drills, trailers, etc., to achieve integrated operations of tilling, planting and transportation.
