Tavol LPG/Dual-Fuel Forklift with over 20 years of production and export experience, offering 1-ton to 3-ton load capacity. Standard lifting height is 3 meters (duplex mast), with options for 3-meter full-free mast and 4 to 6-meter triplex mast.
Our forklifts run on LPG (liquefied petroleum gas) with a dual-fuel (LPG/gasoline) option for greater flexibility. Equipped with high-efficiency engines for lower emissions and fuel costs, ensuring longer continuous operation per tank.
Our LPG forklifts accept OEM and ODM service. For more details, welcome contact us.

120hp tractor with cabin 16+8 gear

Model		Tavol-2004
Machine parameters	Type	4×4
	Rated Traction( KN)	38
	PTO Max Power (KW)	125
	Dimensions(mm)	5350*2350*3030
Wheelbase(mm)		2668
Track(mm)	Front wheel(mm)	1900
	Rear wheel(mm)	1700-2300



Model		Tavol-504
Machine parameters	Type	4×4
	Rated Traction( KN)	7.5
	PTO Max Power (KW)	31
	Dimensions(mm)	3560×1450×2150
Wheelbase(mm)		2016
Track(mm)	Front wheel(mm)	1350-1550
	Rear wheel(mm)	1300-1500



Model	1LYQ-220/222	1LYQ-320/322	1LYQ-420/422	1LY(T)-225/230	1LY(T)-325/330	1LY(T)-425/430	1LY(T)-525/530	1LY(T)-625/630
Width of cut (mm)	400/440	600/660	800/880	500/600	750/900	1000/1200	1250/1500	1500/1800
Depth of cut (mm）	20-22	20-22	20-22	25-30	25-30	25-30	25-30	25-30
Dia of disc (mm）	510/560	510/560	510/560	660/710	660/710	660/710	660/710	660/710
Q’ty of disc	2	3	4	2	3	4	5	6
Weight (kg)	140	170	230	320	380	450	550	680
Tractor power (hp)	20-30	30-50	40-60	35-55	70-80	80-120	120-150	150-200
Mounted cat	I类三点悬挂Cat I			II类三点悬挂Cat II

This kind of precision corn seeder/corn drill must match with the four-wheel types tractors, which used for seeding the single seed or double seeds accurately (you may chose). The corn drill also sow the crystalline granule fertilizer while seeding. Which can finish furrowing, fertilizing, seeding, covering earth, pressing etc. The effect of Single grain sowing is extremely accurate, that is save seeds; truly achieve a revolutionary innovation in planting industry.

Front end loader
Model		TZ03D	TZ04D	TZ05D	TZ06D	TZ08D	TZ10D	TZ12D
Rated lift capacity	kg	300	400	500	600	800	1000	1200
Max. dump height	mm	1800	2000	2100	2200	2350	2350	2500
Digging depth	mm	100	120	140	140	180	180	200
Bucket capacity	m³	0.18	0.3	0.35	0.4	0.48	0.6	1
Dump angle	(°)	42-45	42-45	42-45	42-45	42-45	42-45	42-45
Weight	kg	400	450	500	550	60	700	800
