Tavol Forklift Price 3T 3.5T LPG Forklift

Share to:

Tavol Forklift Price 3T 3.5T LPG Forklift

Name: Tavol Forklift Price 3T 3.5T LPG Forklift
Brand: Tavol
SKU: 572938317
Rating: 5.0 (99 reviews)

The 3-ton dual-fuel forklift adopts an advanced LPG (liquefied petroleum gas)/diesel dual power system, which can intelligently switch fuel modes according to operational requirements, taking into account both power performance and operational economy.

Equipped with a high-efficiency turbocharged engine, it has a rated load of 3 tons and a maximum climbing grade of 20%, making it suitable for high-intensity outdoor operations.

Capacity(Kg):	3000
Fork size (mm):	1220x122x45
Availability:

Quantity:



Inquire Add to Basket

Model:
CPQYD30
Brand:
Tavol

Product Description

Technical Parameters

Model	CPQYD20	CPQYD25	CPQYD30	CPQYD35	CPQYD40
Rated Loading Capacity(kg)	2000	2500	3000	3500	4000
Load Center Distance(mm)	500	500	500	500	500
Max Lifting Speed(full load)(mm/sec)	400	400	470	470	390
Max Driving Speed(Full/Empty load)(km/h)	17/19	17/19	17/19	17/19	17/19
Fork Lifting Height(mm)	3000	3000	3000	3000	3000
Mast Tilt Angle(Forward and Backward)	6°/12°	6°/12°	6°/12°	6°/12°	6°/12°
Min. Turning Radius(mm)	2450	2450	2530	2530	2720
Min. Ground Clearance(mm)	110	110	135	135	145
Length(including Fork)(mm)	3720	3720	3970	3970	4100
Width(mm)	1160	1160	1230	1230	1230
Height From Ground to Overhead Guard(mm)	2095	2095	2110	2110	2115
Wheel base(mm)	1640	1640	1775	1775	1900
Front Wheel Track(mm)	970	970	1000	1000	1060
Rear Wheel Track(mm)	970	970	970	970	970
Front Wheel Tire	7.00-12	7.00-12	28*9-15	28*9-15	250-15
Rear Wheel Tire	6.00-9	6.00-9	6.50-10	6.50-10	6.50-10
Self Weight(kg)	3470	3750	4120	4490	4850
Standard Fork Length(mm)	1220	1220	1220	1220	1220
Engine Rated Power(kw)	37.4	37.4	37.4	37.4	37.4
Engine Speed at Rated Power(rpm)	2300	2300	2300	2300	2300
Engine Maximum Torque(Nm)	176.5	176.5	176.5	176.5	176.5
Engine Speed at Maximum Torque(rpm)	1600	1600	1600	1600	1600
