CPD30
Tavol
| 3 ton diesel forklift performance parameters | |||||||
| Brand | TAVOL | ||||||
| Model | CPCD30 | ||||||
| DriveForm | Diesel | ||||||
| Rated Lifting Load | kg | 3000 | |||||
| Load Center Distance | mm | 500 | |||||
| Free lifting Height | mm | 80 | |||||
| Overall Length (With Fork/Without Fork) | mm | 3930/2710 | |||||
| Width | mm | 1230 | |||||
| Overhead Guard Height | mm | 2145 | |||||
| Wheelbase | mm | 1700 | |||||
| Minimum Ground Clearance | mm | 135 | |||||
| Mast Tilt Angle(Front/Rear) | % | 6/12 | |||||
| Tire No(Front ) | 28*9-15-12PR | ||||||
| Tire No(Rear) | 6.50-10-10PR | ||||||
| Minimum Turning Radius(Outside) | mm | 2440 | |||||
| Minimum Right Angle Aisle Width | mm | 4315 | |||||
| Fork Size | mm | 1220*122*50 | |||||
| Total Weight | kg | 4250 | |||||
| Engine | Japan Isuzu C240 engine | ||||||
| Type Of Power Shift | Hydraulic Transmission/Automatic | ||||||
| 3 ton diesel forklift performance parameters | |||||||
| Brand | TAVOL | ||||||
| Model | CPCD30 | ||||||
| DriveForm | Diesel | ||||||
| Rated Lifting Load | kg | 3000 | |||||
| Load Center Distance | mm | 500 | |||||
| Free lifting Height | mm | 80 | |||||
| Overall Length (With Fork/Without Fork) | mm | 3930/2710 | |||||
| Width | mm | 1230 | |||||
| Overhead Guard Height | mm | 2145 | |||||
| Wheelbase | mm | 1700 | |||||
| Minimum Ground Clearance | mm | 135 | |||||
| Mast Tilt Angle(Front/Rear) | % | 6/12 | |||||
| Tire No(Front ) | 28*9-15-12PR | ||||||
| Tire No(Rear) | 6.50-10-10PR | ||||||
| Minimum Turning Radius(Outside) | mm | 2440 | |||||
| Minimum Right Angle Aisle Width | mm | 4315 | |||||
| Fork Size | mm | 1220*122*50 | |||||
| Total Weight | kg | 4250 | |||||
| Engine | Japan Isuzu C240 engine | ||||||
| Type Of Power Shift | Hydraulic Transmission/Automatic | ||||||
