TL904
TAVOL
8701931000
Technical Parameters
| Model | Tavol-904 | |
| Machine parameters | Type | 4×4 |
| Rated Traction( KN) | 23.7 | |
| PTO Max Power (KW) | 60.8 | |
| Dimensions(mm) | 4300×2350×3000 | |
| Wheelbase(mm) | 2200 | |
| Track(mm) | Front wheel(mm) | 1650-1950 |
| Rear wheel(mm) | 1620-2020 | |
| Ground clearance(mm) | Minimum ground clearance(mm) | 365 |
| Minimum turning cricle radius | Use unilateral braking | ≤4.3 |
| Not unilateral braking | ≤4.8 | |
| Minimum use quality | 4110 | |
| Gearbox | 16F+8R Shuttle Shift | |
| Steering System | hydraulic steering gear | |
| Drive Train | Clutch | double acting clutch |
| Working equipment | Maximum lifting force at 610mm(KN) | 16.8 |
| Suspension mechanism | Three-piont suspension type 2 | |
| PTO shaft | PTO Spedd(r/min) | 540/760/1000 |
| Tire | Front wheel specifications | 12.4-28/13.6-24 |
| Rear wheel specifications | 16.9-34/18.4-30/18.4-34 | |
| Engine | Type | Inline, 4 stroke, Water cooled |
| Cylinder | 4 | |
| Optional | Cabin | AC/Heater |
| Roll bar | ||
| Canopy | ||
| This parameter table is for reference only, everything is based on actual products | ||
Product Details:
Cloent Project
Agricultural machinery:
Welcome to contact us:
Technical Parameters
| Model | Tavol-904 | |
| Machine parameters | Type | 4×4 |
| Rated Traction( KN) | 23.7 | |
| PTO Max Power (KW) | 60.8 | |
| Dimensions(mm) | 4300×2350×3000 | |
| Wheelbase(mm) | 2200 | |
| Track(mm) | Front wheel(mm) | 1650-1950 |
| Rear wheel(mm) | 1620-2020 | |
| Ground clearance(mm) | Minimum ground clearance(mm) | 365 |
| Minimum turning cricle radius | Use unilateral braking | ≤4.3 |
| Not unilateral braking | ≤4.8 | |
| Minimum use quality | 4110 | |
| Gearbox | 16F+8R Shuttle Shift | |
| Steering System | hydraulic steering gear | |
| Drive Train | Clutch | double acting clutch |
| Working equipment | Maximum lifting force at 610mm(KN) | 16.8 |
| Suspension mechanism | Three-piont suspension type 2 | |
| PTO shaft | PTO Spedd(r/min) | 540/760/1000 |
| Tire | Front wheel specifications | 12.4-28/13.6-24 |
| Rear wheel specifications | 16.9-34/18.4-30/18.4-34 | |
| Engine | Type | Inline, 4 stroke, Water cooled |
| Cylinder | 4 | |
| Optional | Cabin | AC/Heater |
| Roll bar | ||
| Canopy | ||
| This parameter table is for reference only, everything is based on actual products | ||
