CPCD30
Tavol
8427109000
Mast and Lift Height for Fork Lift
| / | 2- Stage Mast 2- | Triplex Mast |
| 1 | 3 m | 4.5m |
| 2 | 3 m with full free mast | 5m |
| 3 | 3.5m | 5.5m |
| 4 | 4m | 6m |
| 5 | 4.5m | 7m |
| 6 | 5m | / |
Fork Length for Forklift
1. Standard: 1070 mm for 2t & 2.5t forklift
2. Standard: 1220 mm for 3t & 3.5t forklift
3. Optional: 1370mm, 1520mm, 1670mm, 1820mm for forklift
Attachment for Fork Lift
Optional side shifter, fork positioner, paper roll clamp, bale clamp ,rotating clamp etc.
Product specifications
| Model | CPCD30 |
| Rated Loading Capacity(kg) | 3000 |
| Load Center Distance(mm) | 500 |
| Drive Form | Diesel |
| Fork Lifting Height(mm) | 3000 |
| Mast Tilt Angle (Forward and Backward) | 6°/12° |
| Length (Including Fork)(mm) | 3970 |
| Width(mm) | 1230 |
| Height(Door Frame Indented) | 2110 |
| Height From Ground to Overhead Guard(mm) | 2105 |
| Wheel Base(mm) | 1775 |
| Self Weight(kg) (kg) | 4250/4290 |
| Fork Width(mm) | 122 |
| Standard Fork Length(mm) | 1220 |
| Transmission form | Hydraulic |
Optional
What type of machinery do we offer?
* Diesel Forklift: 1.5ton 2ton 2.5ton 3ton 3.5ton 4ton 4.5ton 5ton 6ton 7ton 8ton 10ton 12ton
* Electric Forklift: 1ton, 1.5ton, 2ton, 2.5ton, 3ton, 3.5ton, 4ton, 5ton
* LPG Forklift: 1ton, 1.5ton, 2ton, 2.5ton, 3ton, 3.5ton, 4ton, 5ton
* Rough Terrain Forklift: 3ton, 3.5ton, 4ton, 5ton * Telescopic Handler Forklift: 3ton, 3.5ton, 4ton, 5ton, 6ton
