Tavol Agricultural Tractor 30hp 45hp 50hp 60hp Tractor 4wd Farm Walking Tractor

1. Product Overview
The 45hp tractor is an important part of agricultural machinery, and is favored by farmers and agricultural cooperatives for its moderate power and wide applicability. These tractors can perform a variety of field operations, such as ploughing, sowing, harvesting, etc., which greatly improves agricultural production efficiency.

2. Main Features
Powerful power: The 45hp tractor is matched with a high-quality engine, with strong power and large torque reserve coefficient, which can meet the needs of various agricultural operations.
Wide range of applications: The enhanced two-speed power output and the wide range of matching machines can easily cope with various agricultural operating conditions.
Humanized design: The new generation of streamlined hood is beautiful and atmospheric, meeting the performance requirements of safety, dust prevention, noise reduction, heat dissipation, etc. At the same time, the optimized design of the whole vehicle's ergonomics enhances the driver's sense of security and comfort.
High efficiency and low consumption: The gearbox has reasonable gears, high operating efficiency, and good fuel economy. The hydraulic lifting device adopts force adjustment, position adjustment, and force and position separate control to accurately control the operating load, effectively improve the working condition of the engine, and improve fuel economy and operation quality.

Availability:
Quantity:
  • TL504

  • TAVOL

  • 8701921000

微信图片_20240910090953

The 45hp tractor is a mechanical equipment suitable for a variety of agricultural operation scenarios. It uses a 4-cylinder diesel engine with strong power and low fuel consumption, which is suitable for small farmland operations. The tractor is equipped with an F8+R8 gearbox, which has smooth gear shifting and flexible control. The hydraulic steering system makes driving easier and more labor-saving. Its basic functions include various agricultural operations such as tillage, sowing, and harvesting, which can meet the diverse needs of farmers. In addition, the 45hp tractor also has good passability and stability, and can operate efficiently in complex farmland environments. In summary, the 45hp tractor is an agricultural machinery equipment with comprehensive functions, stable performance, and easy operation.

IMG_20250528_175458Technical Parameters

Model TL454
Type 4x4
Machine parameters PTO power (KN) 28.2
Rated Traction (KN) 6.8
Dimensions (mm) 3300×1440×1870
Wheelbase (mm) 1975
Track (mm) Front wheel 1225-1425
Rear wheel 1160-1300
Minimum ground clearance (mm) 290
Turning circle radius Unilateral  braking 2.3
Not unilateral braking 3
Weight (KG) 1402
Drive Train Clutch Single stage cluth
Gearbox 8+2 shift
Walking steering Tire Front wheel  6.00-16/6.5-16
Rear wheel  9.4-24/11.2-24
Braking system Service brake Mechanical hoof type
Parking brake Locking pedal type
Working equipment Maximum lifting force at 610mm(KN) 6.64
Suspension mechanism Three-point suspension type 1
PTO shaft PTO speed r/min 540/760
Engine Engine brand LAIDONG
Engine type Diesel engine
Engine cylinder 4
Start Start method Electric
Main fill volume (L) Radiater 10
Fuel tank 21
Engine sump 3.5
Gearbox oil  11
Lifter 9
This parameter table is for reference only, everything is based on actual products

1751859708713

FAQ

Q1:Are you the factory or the trading company?

A1:We are the factory, we located in Taian City, Shandong Province, China.

Q2:What after-sales service can your company provide?

A2:We can provide technical support and on-site installation support!

Q3:Can you provide spare parts for free?

A3:Of course.

Q4:Can you provide OEM?

A4:Yes,we can.

Q5:How about the delivery time?

A5:5-15 days according to the different quantity.
