TL504
TAVOL
8701931000
| Model | Tavol-504 | |
| Machine parameters | Type | 4×4 |
| Rated Traction( KN) | 10.5 | |
| PTO Max Power (KW) | 31 | |
| Dimensions(mm) | 3315×1570×2230 | |
| Wheelbase(mm) | 1885 | |
| Track(mm) | Front wheel(mm) | 1250 |
| Rear wheel(mm) | 1000-1300 | |
| Ground clearance(mm) | Minimum ground clearance(mm) | 295 |
| Minimum turning cricle radius | Use unilateral braking | ≤3.5 |
| Not unilateral braking | ≤4.0 | |
| Minimum use quality | 1520 | |
| Gearbox | 8F+2R Shuttle Shift | |
| Steering System | hydraulic steering gear | |
| Drive Train | Clutch | double acting clutch |
| Working equipment | Maximum lifting force at 610mm(KN) | 8.3 |
| Suspension mechanism | Three-piont suspension type 1 | |
| PTO shaft | PTO Spedd(r/min) | 540/760/1000 |
| Tire | Front wheel specifications | 6.5-16/7.5-16 |
| Rear wheel specifications | 11.2-24/12.4-24/11.2-28 | |
| Engine | Type | Inline, 4 stroke, Water cooled |
| Cylinder | 4 | |
| Optional | Cabin | AC/Heater |
| Roll bar | ||
| Canopy | ||
| Perfusion volume | Radiater(L) | 10 |
| Fuel tank(L) | 60 | |
| Engine oil pan(L) | 5 | |
| Driveline oil (L) | 20 | |
| Lifter(L) | 9.5 | |
| This parameter table is for reference only, everything is based on actual products | ||
First, moderate and stable power output. The 50hp high-quality diesel engine provides sufficient power for ploughing, rotary tillage, sowing, weeding and light traction tasks, which is neither too powerful (avoiding energy waste) nor insufficient, suitable for small and medium-sized plots. Second, the dedicated sunshade design effectively blocks sunlight, rain and dust, protecting the operator from sunburn and rain, improving comfort during long hours of outdoor work and reducing work fatigue. Third, flexible and easy to operate, with a compact body, it can easily pass through narrow farmland, orchards and greenhouses, and the simple control panel is easy to learn, suitable for operators of all ages.
Cost-effectiveness is its biggest highlight, with moderate price and low fuel consumption, which is affordable for small farmers and individual operators. Durable and reliable, the body is made of high-strength steel, with wear-resistant parts and a stable chassis, adapting to long-term outdoor work and reducing failure and maintenance costs. Multi-functional compatibility, it can be matched with various agricultural tools such as ploughs, harrows and planters to realize one machine with multiple uses and save equipment investment. The sunshade is detachable and easy to store and maintain, and the overall structure is simple, which is convenient for daily inspection and maintenance, making it a practical helper for modern small and medium-sized agricultural operations.
Welcome to contact us:
| Model | Tavol-504 | |
| Machine parameters | Type | 4×4 |
| Rated Traction( KN) | 10.5 | |
| PTO Max Power (KW) | 31 | |
| Dimensions(mm) | 3315×1570×2230 | |
| Wheelbase(mm) | 1885 | |
| Track(mm) | Front wheel(mm) | 1250 |
| Rear wheel(mm) | 1000-1300 | |
| Ground clearance(mm) | Minimum ground clearance(mm) | 295 |
| Minimum turning cricle radius | Use unilateral braking | ≤3.5 |
| Not unilateral braking | ≤4.0 | |
| Minimum use quality | 1520 | |
| Gearbox | 8F+2R Shuttle Shift | |
| Steering System | hydraulic steering gear | |
| Drive Train | Clutch | double acting clutch |
| Working equipment | Maximum lifting force at 610mm(KN) | 8.3 |
| Suspension mechanism | Three-piont suspension type 1 | |
| PTO shaft | PTO Spedd(r/min) | 540/760/1000 |
| Tire | Front wheel specifications | 6.5-16/7.5-16 |
| Rear wheel specifications | 11.2-24/12.4-24/11.2-28 | |
| Engine | Type | Inline, 4 stroke, Water cooled |
| Cylinder | 4 | |
| Optional | Cabin | AC/Heater |
| Roll bar | ||
| Canopy | ||
| Perfusion volume | Radiater(L) | 10 |
| Fuel tank(L) | 60 | |
| Engine oil pan(L) | 5 | |
| Driveline oil (L) | 20 | |
| Lifter(L) | 9.5 | |
| This parameter table is for reference only, everything is based on actual products | ||
First, moderate and stable power output. The 50hp high-quality diesel engine provides sufficient power for ploughing, rotary tillage, sowing, weeding and light traction tasks, which is neither too powerful (avoiding energy waste) nor insufficient, suitable for small and medium-sized plots. Second, the dedicated sunshade design effectively blocks sunlight, rain and dust, protecting the operator from sunburn and rain, improving comfort during long hours of outdoor work and reducing work fatigue. Third, flexible and easy to operate, with a compact body, it can easily pass through narrow farmland, orchards and greenhouses, and the simple control panel is easy to learn, suitable for operators of all ages.
Cost-effectiveness is its biggest highlight, with moderate price and low fuel consumption, which is affordable for small farmers and individual operators. Durable and reliable, the body is made of high-strength steel, with wear-resistant parts and a stable chassis, adapting to long-term outdoor work and reducing failure and maintenance costs. Multi-functional compatibility, it can be matched with various agricultural tools such as ploughs, harrows and planters to realize one machine with multiple uses and save equipment investment. The sunshade is detachable and easy to store and maintain, and the overall structure is simple, which is convenient for daily inspection and maintenance, making it a practical helper for modern small and medium-sized agricultural operations.
Welcome to contact us:
