FB30
Tavol
The 3-ton electric forklift is a clean, efficient, and cost-saving choice for modern warehouses and logistics, combining high performance, low maintenance, and sustainability.Fast Charging/Battery Swap – Lithium-ion models support quick charging (1-2 hours) or battery swapping, while lead-acid batteries offer 6-8 hours of runtime per charge.
Smooth & Precise Control – AC motor ensures instant torque, smooth acceleration, and precise lifting/tilting for accurate load handling.
Smart Features – Some models include regenerative braking, auto-deceleration, and programmable performance settings.
Technical Parameters
| Model | FB30 |
| Loading Capacity(kg) | 3000 |
| Load Center Distance (mm) | 500 |
| Drive Form | Lithium Battery |
| Fork Lifting Height (mm) | 3000 |
| Length (Including Fork) (mm) | 4120 |
| Width (mm) | 1230 |
| Height (Door Frame Indented) (mm) | 2105 |
| Wheel Base (mm) | 1700 |
| Wheel Track (Front/Rear) (mm) | 1000/970 |
| Wheel Tyre (Front/Rear) | 28*9-15-14/6.50-10-10 |
| Self Weight (kg) | 4400 |
| Fork Length (mm) | 1220 |
| Drive Motor Power(KW) | 15 |
| Lifting Motor Power(KW) | 16 |
| Battery (Voltage/Capacity) | 76.8V/205AH |
Optional:
1. China top brand lithium battery,80V/150Ah,76.8V/205Ah,76.8V/280Ah,
76.8V/350AH,80V/525AH,lead acid battery optional,water automatic filling system is poptional;
2.Mast optional: 3/4m duplex mast, 3.6/4/4.5/5/5.5/6m triplex mast, 3/3.3/3.5/4/m duplex full free mast.
3.Forks: 1070/1220/1370/1520/1670/1820/1970mm
4.Transmission: Automatic/manual;
5.Tire: pneumatic/Solid/non-mark solid;
6. Attachments: Side shifter, fork positoner, fork sleeve, paper roller clamp, bale clamp, drum clamp, load extender, rotator,fork clamps, push/pull, etc..
7. Additional: Cabin, heating, fan, air conditioner, high exhaust, paper fold, USB, camera & image, suspension seat, etc.
Success Case
Since its launch, Tavol forklifts have successfully delivered more than 10,000 units worldwide, becoming a reliable partner for warehousing logistics, rental industry and industrial handling. Our products span five continents and serve more than 60 countries. From precision manufacturing in Europe to port freight in South America, from large-scale infrastructure in the Middle East to rapidly developing e-commerce warehousing in Southeast Asia, Tavol forklifts are winning the trust of global customers with their excellent performance!
Global coverage, local service - Tavol forklifts help upgrade world logistics
✔ High-end market in Europe: the first choice for automated warehousing in the UK, France, Germany and other countries
✔ Efficient logistics in the Americas: core equipment for e-commerce and port logistics in Brazil, Mexico, the United States and other countries
✔ Harsh environment in the Middle East: stable operation in high-temperature construction sites and heavy-duty handling scenarios in the UAE and Saudi Arabia
✔ Emerging economies in Asia and Africa: the backbone of logistics in fast-growing markets such as Indonesia, Ghana and South Africa
Full-scenario adaptation, all-weather reliability - tireless porters in the global village
Whether it is a cold chain warehouse in Northern Europe at -30℃, a construction site in the Middle East desert at 50℃, or the ultra-high precision requirements of the dust-free workshop in the electronics industry, Tavol forklifts can do it:
✅ Extreme cold/high temperature adaptability - special steel and intelligent temperature control system ensure stable operation
✅ Clean environment solution - lithium battery power + low noise design to meet the needs of precision manufacturing
✅ High-intensity operation capability - 7×24 hours continuous work, a return-on-investment tool for the rental industry
"Global wisdom, local support" - We work closely with more than 200 international dealers to provide a fast-response after-sales service network to ensure that your operations never stop.
 |  |  |
 |  |  |
Please contact for more information :
