TL504
Tavol
8701911000
| 50HP Tractor Specification | |||||||
| Model | TL504 | ||||||
| Machine parameters | Type | 4×4 | |||||
| Rated Traction( KN) | 6.5 | ||||||
| PTO Max Power (KW) | 18.8 | ||||||
| Dimensions(mm) | 3220×1455×2225 | ||||||
| Wheelbase(mm) | 1730 | ||||||
| Track(mm) | Front wheel(mm) | 1225-1425 | |||||
| Rear wheel(mm) | 960-1300 | ||||||
| Ground clearance(mm) | Minimum ground clearance(mm) | 290 | |||||
| Minimum turning cricle radius | Use unilateral braking | ≤2.3 | |||||
| Not unilateral braking | ≤3 | ||||||
| Minimum use quality | 1400 | ||||||
| Gearbox | 8F+2R Shift | ||||||
| Steering System | Hydraulic steering gear | ||||||
| Drive Train | Clutch | Dual stage clutch | |||||
| Working equipment | Maximum lifting force at 610mm(KN) | ≥17 | |||||
| Suspension mechanism | 3-piont suspension type 1 or 2 | ||||||
| PTO shaft | PTO Spedd(r/min) | 540/760(option: 540/1000) | |||||
| Tire | Front wheel specifications | 6.5-16/7.5-16/8.3-20 | |||||
| Rear wheel specifications | 11.2-24/12.4-24/12.4-28 | ||||||
| Engine | Type | Inline, 4 stroke, Water cooled | |||||
| Cylinder | 4 | ||||||
| Optional | Cabin | Airconditioner + Heater | |||||
| Sunshade | |||||||
| Roll bar | |||||||
