TL2804
TAVOL
8701951010
Technical Parameters:
Model | Tavol-2804 | |
Machine parameters | Type | 4×4 |
Rated Traction( KN) | 50 | |
PTO Max Power (KW) | 162 | |
Dimensions(mm) | 5350*2200*3300 | |
Wheelbase(mm) | 2668 | |
Track(mm) | Front wheel(mm) | 1900 |
Rear wheel(mm) | 1700-2300 | |
Ground clearance(mm) | Minimum ground clearance(mm) | 480 |
Minimum turning cricle radius | Use unilateral braking | ≤6.2 |
Not unilateral braking | ≤7.0 | |
Minimum use quality | 6660 | |
Gearbox | 16F+16R Shuttle Shift | |
Steering System | hydraulic steering gear | |
Drive Train | Clutch | double acting clutch |
Working equipment | Maximum lifting force at 610mm(KN) | 46 |
Suspension mechanism | Three-piont suspension type 3 | |
PTO shaft | PTO Spedd(r/min) | 540/1000 |
Tire | Front wheel specifications | 16.9-28 |
Rear wheel specifications | 20.8-38 | |
Engine | Type | Inline, 4 stroke, Water cooled |
Cylinder | 4 | |
Optional | Cabin | AC/Heater |
Roll bar | ||
Canopy | ||
Perfusion volume | Radiater(L) | 28 |
Fuel tank(L) | 325 | |
Engine oil pan(L) | 22 | |
Lifter(L) | 110 | |
This parameter table is for reference only, everything is based on actual products | ||
Client Project
Tractor Farm machinery
Welcome to contact us:
