TL704
TAVOL
8701921000
Model | Tavol-704 | |
Machine parameters | Type | 4×4 |
Rated Traction( KN) | 14 | |
PTO Max Power (KW) | 43 | |
Dimensions(mm) | 3250×1680×2560 | |
Wheelbase(mm) | 2016 | |
Track(mm) | Front wheel(mm) | 1350-1550 |
Rear wheel(mm) | 1300-1500 | |
Ground clearance(mm) | Minimum ground clearance(mm) | 295 |
Minimum turning cricle radius | Use unilateral braking | ≤4.0 |
Not unilateral braking | ≤4.6 | |
Minimum use quality | 2000 | |
Gearbox | 8F+8R Shuttle Shift | |
Steering System | hydraulic steering gear | |
Drive Train | Clutch | double acting clutch |
Working equipment | Maximum lifting force at 610mm(KN) | 12 |
Suspension mechanism | Three-piont suspension type 1 | |
PTO shaft | PTO Spedd(r/min) | 540/760/1000 |
Tire | Front wheel specifications | 6.00-16 |
Rear wheel specifications | 12.4-28 | |
Engine | Type | Inline, 4 stroke, Water cooled |
Cylinder | 4 | |
Engine Brand | YTO, XICHAI, LAIDONG; EURO5 4L28V50 | |
Optional | Cabin | AC/Heater |
Roll bar | ||
Canopy | ||
Perfusion volume | Radiater(L) | 10 |
Fuel tank(L) | 60 | |
Engine oil pan(L) | 5 | |
Driveline oil (L) | 20 | |
Lifter(L) | 9.5 | |
This parameter table is for reference only, everything is based on actual products | ||
Client feedback
 |  |  |
| Project in Estonia | Project in Syria | Project in Bosnia and Herzegovina |
 |  |  |
| Project in Czech Republic | Project in Italy | Project in France |
 | tractor with Cabin (With AC & heater) 70hp, 8F+8R shift, Shuttle stage clutch, 4 Cylinder engine Engine Brand: YTO, XICHAI, LAIDONG Tyre Size: 6.5-16/11.2-24, 7.5-16/12.4-24, 8.3-20/12.4-28, 280/70R20-380/85R24 (You can choose the size and type of tire according to your needs) Hydraulic 3 point linkage PTO speed: 540/760 2 way hydraulic output With front and rear ballast. Color and logo depends on customer's request |
Ms.Joily Sun
Wechat/WhatsApp :+8615166062329
Email:joily@tavolgroup.com
