TL804
TAVOL
8701931000
The 80hp tractor is a high-performance agricultural workhorse designed to handle demanding farming tasks with exceptional efficiency. Combining robust power with advanced engineering, it excels in operations such as deep tillage, heavy-duty cultivation, large-scale planting, and material handling. Built for durability and ease of maintenance, the 80hp tractor incorporates a heavy-duty frame, ergonomic operator controls, and low-emission technology to meet modern agricultural demands.
Technical Parameters
| Model | TL804 | |
| Machine parameters | Type | 4×4 |
| Rated Traction( KN) | 12 | |
| PTO Max Power (KW) | 50 | |
| Dimensions(mm) | 3910×1720×2720 | |
| Wheelbase(mm) | 2040 | |
| Track(mm) | Front wheel(mm) | 1350-1550 |
| Rear wheel(mm) | 1300-1500 | |
| Ground clearance(mm) | Minimum ground clearance(mm) | 400 |
| Minimum turning cricle radius | Use unilateral braking | 4.0±0.30 |
| Not unilateral braking | 4.6±0.30 | |
| Minimum use quality | 2440 | |
| Gearbox | 12F+12R Shuttle Shift | |
| Steering System | hydraulic steering gear | |
| Drive Train | Clutch | double acting clutch |
| Working equipment | Maximum lifting force at 610mm(KN) | ≥14 |
| Suspension mechanism | Three-piont suspension type 1 | |
| PTO shaft | PTO Spedd(r/min) | 540/760(option: 540/1000) |
| Tire | Front wheel specifications | 8.3-20/8.3-24/9.5-24/11.2-24 |
| Rear wheel specifications | 12.4-24/11-32/14.9-30/16.9-30 | |
| Engine | Type | Inline, 4 stroke, Water cooled |
| Cylinder | 4 | |
| Optional | Cabin | AC/Heater |
| Roll bar | ||
| Canopy | ||
| Perfusion volume | Radiater(L) | 12 |
| Fuel tank(L) | 64 | |
| Hydraulic steering oil (L) | 0.8 | |
| Steering system oil (L) | 20 | |
| This parameter table is for reference only, everything is based on actual products | ||
