| Capacity(Kg): | |
|---|---|
| Fork size (mm): | |
| Quantity: | |
CPQYD
Tavol
8427209000
Model | CPQYD35H | |||||
Rated capacity | KG | 3500 | ||||
Load center | MM | 500 | ||||
Lifting height(max.) | MM | 3000 | ||||
Free lift height | MM | 80 | ||||
Mast Tilt Angle | F/R | Deg | 6°/12° | |||
Lifting speed (max.) | Loaded | MM/s | 470/420 | |||
Traction(max) | Loaded/Unloaded | KN | 15/10 | |||
Traveling speed(max.) | Loaded/Unloaded | KM/h | 18/20 | |||
Grade ability under full Load(max) | Loaded/Unloaded | % | 15/20 | |||
Turning radius(min) | MM | 2540 | ||||
The minimum clearance from the ground | MM | 135 | ||||
Wheelbase | MM | 1775 | ||||
Wheel tread | F/R | MM | 1000/970 | |||
front overhang | MM | 465 | ||||
Dimensions | Length | With fork | MM | 4025 | ||
Width | MM | 1230 | ||||
Closed mast height | MM | 2110 | ||||
Overhead guard height | MM | 2105 | ||||
Max. Height at work | With/without backrest | MM | 4270 | |||
Fork size | LXWXT | MM | 1220x122x45 | |||
Standard fork length | MM | 1220 | ||||
Service Weight | KG | 4600/4640 | ||||
Tire | 2 units | Inflatable Tyre | ||||
2 units | Inflatable Tyre | |||||
Motor | Brand | Nissan K25 | ||||
Maximum output power(Kw) | 37.4 | |||||
Rated speed(rpm) | 2300 | |||||
Max. Torque (Nm) | 177 | |||||
Maximum torque speed(rpm) | 1600 | |||||
The engine form | Hydraulic | |||||
Optional
What type of machinery do we offer?
* Diesel Forklift: 2ton 2.5ton 3ton 3.5ton 4ton 4.5ton 5ton 6ton 7ton 8ton 10ton
* Electric Forklift: 1ton, 1.5ton, 2ton, 2.5ton, 3ton, 3.5ton, 4ton, 5ton
* LPG Forklift: 2ton, 2.5ton, 3ton, 3.5ton, 4ton
* Rough Terrain Forklift: 3ton, 3.5ton, 4ton, 5ton * Telescopic Handler Forklift: 3ton, 3.5ton, 4ton, 5ton, 6ton
Contact :
Whatsapp:+86 19153202320 E-Mail: jessamine@tavolgroup.com Wechat: +86 19153202320(Phone)
