CPCD70
Tavol
Product specifications
| Model | CPCD70 |
| Rated Loading Capacity(kg) | 7000 |
| Load Center Distance(mm) | 600 |
| Drive Form | Diesel |
| Fork Lifting Height(mm) | 3000 |
| Mast Tilt Angle (Forward and Backward) | 6°/12° |
| Length (Including Fork)(mm) | 4800 |
| Width(mm) | 1995 |
| Height From Ground to Overhead Guard(mm) | 2420 |
| Wheel Base(mm) | 2250 |
| Self Weight(kg) (kg) | 9500 |
| Min. Ground Clearance(mm) | 230 |
| Standard Fork Length(mm) | 1220 |
| Transmission form | Hydraulic |
Optional
1.Xinchai engine, Quanchai engine; optional Japan Isuzu, Mitsubishi engine and others;
2.Optional side shifter, fork positioner and other attachments;
3.Standard 2-stages 3000mm mast, optional 2-stages and 3-stages full free 4500mm-7500mm mast;
4.Standard 1220mm fork, optional 1370mm, 1520mm, 1670mm and 1820mm forks;
5.Mechanical and Automatic transmission can be choosen;
6.Standard pneumatic tire, optional solid tire.
